Testing API-Driven Components in Storybook

A component that fetches data will hang on “Loading…” or throw in Storybook because there is no backend to answer its request — the fix is to intercept that request at the network layer with Mock Service Worker, not to stub the hook.

If you’ve ever watched a component sit on “Loading…” in Storybook with nothing in the console to explain it, this is the cause: no server is there to answer the request it fires on mount. Set the mock up once and every story you write gets the same treatment for free.

This guide sets up msw-storybook-addon (which requires MSW 2.x) on Storybook 10, then builds a UserList component with four stories (success, loading, error, and empty) and closes the loop by turning those mocked states into automated interaction tests.

Why do data-fetching components break in Storybook?

Storybook renders components in isolation, with no application shell and no server. An “app component” that calls fetch, useQuery, or Apollo on mount fires a request that nothing answers, so it either sits on its loading branch forever or throws when the promise rejects. The instinct is to stub the hook: swap useQuery for a mock that returns canned data. Don’t. Stubbing the hook couples your story to one data library and to internal component structure, and the stub is useless the moment you want to run the same scenario in a Node test.

Mock at the network layer instead. MSW registers a service worker that intercepts outgoing requests in the browser and returns responses you define, so your component runs its real fetching code path unchanged. The same handlers run under Node via setupServer, which is what makes them portable across Storybook, Vitest, and CI. You author the scenario once; it works everywhere the component runs.

How do you set up the Storybook mock API stack?

Install both packages, generate the service worker, register the loader, and point Storybook at the worker file. This one-time setup follows Storybook’s guide to mocking network requests.

npm install msw msw-storybook-addon --save-dev
npx msw init public/

npx msw init public/ writes mockServiceWorker.js into your static directory. Register the addon globally by adding mswLoader to loaders in .storybook/preview.ts. Loaders run before a story renders, which is why the addon uses a loader rather than a decorator:

import type { Preview } from '@storybook/react-vite';
import { initialize, mswLoader } from 'msw-storybook-addon';

initialize();

const preview: Preview = {
  loaders: [mswLoader],
};

export default preview;

Then serve the generated worker by listing your public folder in staticDirs inside .storybook/main.ts. The old start-storybook -s public flag no longer exists in Storybook 10:

import type { StorybookConfig } from '@storybook/react-vite';

const config: StorybookConfig = {
  framework: '@storybook/react-vite',
  stories: ['../src/**/*.stories.@(js|jsx|ts|tsx)'],
  staticDirs: ['../public'],
};

export default config;

The success story

Here is the component under test, a UserList that fetches an array and renders one of four UI branches. Note the accessible role="status" and role="alert", which the tests later query against.

// UserList.tsx
import { useEffect, useState } from 'react';

type User = { id: number; name: string };
const endpoint = 'https://api.example.com/users';

export function UserList() {
  const [status, setStatus] = useState<'loading' | 'success' | 'error'>('loading');
  const [users, setUsers] = useState<User[]>([]);

  useEffect(() => {
    fetch(endpoint)
      .then((res) => {
        if (!res.ok) throw new Error(res.statusText);
        return res.json();
      })
      .then((data) => {
        setUsers(data);
        setStatus('success');
      })
      .catch(() => setStatus('error'));
  }, []);

  if (status === 'loading') return <p role="status">Loading…</p>;
  if (status === 'error') return <p role="alert">Something went wrong.</p>;
  if (users.length === 0) return <p>No users yet.</p>;

  return (
    <ul>
      {users.map((u) => (
        <li key={u.id}>{u.name}</li>
      ))}
    </ul>
  );
}

Set the handlers per story through parameters.msw.handlers. In MSW v2, http.get replaces rest.get, and the HttpResponse class replaces the ctx utilities:

// UserList.stories.tsx
import type { Meta, StoryObj } from '@storybook/react-vite';
import { http, HttpResponse, delay } from 'msw';
import { UserList } from './UserList';

const endpoint = 'https://api.example.com/users';

const meta = { component: UserList } satisfies Meta<typeof UserList>;
export default meta;
type Story = StoryObj<typeof meta>;

export const Success: Story = {
  parameters: {
    msw: {
      handlers: [
        http.get(endpoint, () =>
          HttpResponse.json([
            { id: 1, name: 'Ada Lovelace' },
            { id: 2, name: 'Alan Turing' },
          ]),
        ),
      ],
    },
  },
};

Modeling every state

The happy path is where most tutorials stop, and it’s the least interesting story. The value of network-layer mocking is that one handler swap produces every state your component can enter. Session replays of API-driven UIs routinely surface states developers never storyboarded: a spinner that never resolves because a request hung, or an empty response that renders as a broken layout instead of an empty state. Storybook plus MSW is where you author and assert exactly those states before they ship.

The delay function accepts an 'infinite' mode that holds the request pending forever, the reliable way to freeze a component on its loading branch. Import delay from msw and await it inside an async resolver:

export const Loading: Story = {
  parameters: {
    msw: {
      handlers: [
        http.get(endpoint, async () => {
          await delay('infinite');
          return HttpResponse.json([]);
        }),
      ],
    },
  },
};

export const Error: Story = {
  parameters: {
    msw: { handlers: [http.get(endpoint, () => HttpResponse.json(null, { status: 500 }))] },
  },
};

export const Empty: Story = {
  parameters: {
    msw: { handlers: [http.get(endpoint, () => HttpResponse.json([]))] },
  },
};

MSW mocks GraphQL the same way (graphql.query('AllUsers', () => HttpResponse.json({ data }))), so the pattern carries to Apollo, urql, and React Query without change.

From viewing to testing

A mocked story you only look at is documentation; add a play function and it becomes an automatable component test. Import expect from storybook/test (the current module, which replaced Storybook 8’s @storybook/test) and assert on the rendered result:

import { expect } from 'storybook/test';

// on Success:
play: async ({ canvas }) => {
  await expect(await canvas.findByText('Ada Lovelace')).toBeInTheDocument();
},

// on Loading:
play: async ({ canvas }) => {
  await expect(canvas.getByRole('status')).toBeInTheDocument();
},

For the infinite-delay Loading story, assert that the spinner is present. Don’t await resolution, since the request pends forever by design. These stories run through the Vitest addon, which executes them as component tests in Playwright’s Chromium browser from the Storybook UI, the terminal, or CI. Because MSW handlers are environment-agnostic, the same success/error/empty handlers back a standalone Vitest test via setupServer, and Chromatic snapshots each story for visual regression.

Mock at the network layer, model all four states, and attach a play function to each: that turns a folder of stories into a live test suite that catches the loading-forever and broken-empty-state bugs before they reach production. Start by adding the loading, error, and empty stories to one existing app component today. The handlers you write there are the same ones your Vitest tests will reuse.

FAQs

Why is my component stuck on 'Loading…' in Storybook even after installing msw-storybook-addon?

The component is stuck because either no MSW handler matches its request or the addon's loader is not wired. Confirm you added mswLoader to the loaders array in .storybook/preview and called initialize(), that public was generated with npx msw init and listed in staticDirs, and that a handler in parameters.msw.handlers matches the exact request URL and method. A URL mismatch leaves the request unhandled and the component pending forever.

What is the difference between mocking at the network layer with MSW and stubbing the fetch hook?

Network-layer mocking with MSW intercepts the actual outgoing request and returns a response, so the component runs its real fetching code path unchanged and the same handlers work in the browser, in Node via setupServer, and in Chromatic. Stubbing the hook replaces useQuery or fetch with canned data, which couples the story to one data library and to internal component structure, and cannot be reused in a Node test.

Does msw-storybook-addon work with MSW v1 handlers like rest.get and res(ctx.json())?

No. Since version 2.0.0 the addon requires MSW 2.0.0 or higher, and MSW v2 removed the rest namespace and the res(ctx.json()) resolver signature. Rewrite handlers using http.get and the HttpResponse class, for example http.get(url, () => HttpResponse.json(data)). MSW v1 code will not run against the current addon and must be migrated using MSW's official 1.x to 2.x migration guide.

Why does my infinite-delay loading story hang when run as a test?

A story using await delay('infinite') pends its request forever by design, so a play function that awaits the resolved UI never completes. Assert only that the pending UI is present, for example that the spinner with role status renders, rather than awaiting resolution. If a Node or Vitest test must complete cleanly, use a finite delay such as delay(1000) instead of the infinite mode for that scenario.
